| Specifications |
 |
| Micrometer screw thread | | M6x0.25
|
|
|
|
| Sensitivity | | 0.5 μm
|
|
|
|
| Scale division | | 2.5 μm
|
|
|
|
| Axial load capacity | | 50 N |
|
|
|
|
|
|
|
Product added to the Wishlist
| Ordering Information |
|
| Model |
|
Travel, mm |
|
Gradation, µm |
|
L, mm |
|
l, mm |
|
Weight, kg |
|
|
|
|
|
|
| 9SM127M-10 |
|
10 |
|
2.5 |
|
45 |
|
21 |
|
0.05 |
|
|
|
|
|
| 9SM127M-5 |
|
5 |
|
2.5 |
|
40 |
|
16 |
|
0.05 |
|
|
|
|
|
|
|
