Specifications |
 |
Travel range |  | 20 mm
|
 |
 |
 |
Resolution (full step) |  | 2 μm
|
 |
 |
 |
 | 1/256 step |  | 0.0078 μm
|
 |
 |
 |
Encoder pulses per revolution |  | by request
|
 |
 |
 |
Lead screw pitch |  | 2 mm
|
 |
 |
 |
Max. speed |  | 4 mm/s
|
 |
 |
 |
Max. load capacity |  | 200 kg
|
 |
 |
 |
Uni-directional Repeatability |  | 1.5 μm
|
 |
 |
 |
Bi-directional Repeatability |  | 3 μm
|
 |
 |
 |
Accuracy |  | ±5 μm
|
 |
 |
 |
Stepper motor |  | 6018
|
 |
 |
 |
Motor connector |  | HDB15(M)
|
 |
 |
 |
Weight |  | 45 kg |
 |
 |
 |
|
 |
 |
 |
Product added to the Wishlist
Ordering Information |
 |
Model |
 |
 |
 |
|
 |
|
 |
 |
 |
 |
8MVT400-20-60 |
 |
 |
 |
|
 |
|
 |
 |
 |
|
|
