| Specifications |
 |
| Travel range | |
|
|
|
|
| 8MAV-8 | | 8 mm
|
|
|
|
| 8MAV-16 | | 16 mm
|
|
|
|
| Resolution in full step | | 0,051 μm
|
|
|
|
| Lead screw pitch | | 0,5 mm
|
|
|
|
| Reduction gear ratio | | 49:1
|
|
|
|
| Maximum speed | | 0,102 mm/s
|
|
|
|
| Maximum force | | 150 N
|
|
|
|
| Vacuum compatible cable | | integrated, 0,6 m length
|
|
|
|
| Motor connector (for testing) | | HDB15(M)
|
|
|
|
| Vacuum compatible stepper motor | | VSS19
|
|
|
|
| Limit switches | | none
|
|
|
|
| Weight | |
|
|
|
|
| 8MAV-8 | | 0,155 kg
|
|
|
|
| 8MAV-16 | | 0,2 kg
|
|
|
|
| Recommended controllers | | 8SMC5-USB |
|
|
|
|
|
|
|
Product added to the Wishlist
| Ordering Information |
|
| Model |
|
|
|
|
|
|
|
|
|
|
| 8MAV-16 |
|
|
|
|
|
|
|
|
|
| 8MAV-8 |
|
|
|
|
|
|
|
|
|
|
|
