Specifications
| Model |
8MT40-150BS1 |
8MT40-200BS1 |
| Kinematics & Feedback information |
| Travel Range, mm |
150 |
200 |
| Resolution in full step, µm |
5 |
| Encoder type |
On request |
| Encoder resolution |
On request |
| Backlash, µm |
1 |
| Maximum speed, mm/s |
20 |
| Limits switches |
Hall sensors |
| Limit switch polarity |
Pushed is closed |
| Load, Guiding & Transmission Information |
| Ball screw pitch, mm |
1 |
| Load capacity horizontal, kg |
6 |
| Load capacity vertical, kg |
4 |
| Stepper motor model |
28 |
| Control, Communication and Cabling |
| Recommended Controllers |
8SMC4-USB |
| Recommended Power Supply |
PUP120-17 |
| Connector |
HDB15(M) |
| Cable Length, m |
1.8 |
| Material & Environment Conditions |
| Housing Material |
Aluminum |
| Housing Coating (Finish) |
Black Anodizing |
| Environment Pressure |
Atmosphere ( on request up to 10-3 torr) |
| Accessories |
| XY configuration |
Direct connection |
| Additional Details |
| Dimensions of Moving Platform (W x L), mm |
38.5 x 32 |
| Measurement System |
Metric |
| Weight, kg |
0.9 |
1 |
|
