| Specifications |
 |
| Travel range | |
|
|
|
|
| 8CMA16DC-13/15 | | 13 mm
|
|
|
|
| 8CMA16DC-25/15 | | 25 mm
|
|
|
|
| Resolution | | 0.0281 μm
|
|
|
|
Minimum Incremental
Motion | |
0.1 μm
|
|
|
|
| Lead screw pitch | | 0.25 mm
|
|
|
|
| Max.speed | | 0.15 mm/s
|
|
|
|
| Nominal force | | 30 N
|
|
|
|
| Tip shape | | Round. Flat on request.
|
|
|
|
| Cable | | integrated, 1.2 m length
|
|
|
|
| Motor connector | | HDB15(M)
|
|
|
|
| DC motor | | DCE1524
|
|
|
|
| Weight | |
|
|
|
|
| 8CMA16DC-13/15 | | 0.12 kg
|
|
|
|
| 8CMA16DC-25/15 | | 0.15 kg
|
|
|
|
Recommended
controllers | | 8SMC5-USB,
8DCMC1-USB
|
|
|
|
Optocoupler end
limit switches | | 2
|
|
|
|
| Switch polarity | | pushed is open |
|
|
|
|
|
|
|
Product added to the Wishlist
| Ordering Information |
|
| Model |
|
|
|
|
|
|
|
|
|
|
| 8CMA16DC-13/15 |
|
|
|
|
|
|
|
|
|
| 8CMA16DC-25/15 |
|
|
|
|
|
|
|
|
|
| 8CMA16DCV-13/15 |
|
|
|
|
|
|
|
|
|
| 8CMA16DCV-25/15 |
|
|
|
|
|
|
|
|
|
|
|
