| Specifications |
 |
| Rotation range | | 360°
|
|
|
|
| Horizontal load capacity | | 10000 N
|
|
|
|
| Radial load capacity | | 5000 N
|
|
|
|
| Bearing type | | Cross roller bearing
|
|
|
|
| Resolution in full step | | 12 arcsec
|
|
|
|
| Bidirectional repeatability | | 30 arcsec
|
|
|
|
| Radial runout | | 10 µm
|
|
|
|
| Axial runout | | 15 µm
|
|
|
|
| Transmission accuracy | | 60 arcsec
|
|
|
|
| Gear ratio | | 1:540
|
|
|
|
| Wobble | | 30 arcsec
|
|
|
|
| Backlash | | 10 arcsec
|
|
|
|
| Maximum rotation speed | | 2 turn/min
|
|
|
|
| Dynamic tilting torque | | 1000 Nm
|
|
|
|
| Static tilting torque | | 2000 Nm
|
|
|
|
| Tilting torque stiffness | | 600 Nm/arcmin
|
|
|
|
| Torsion stiffness | | 4x105 Nm/rad
|
|
|
|
| Motor | | 5918 (200 steps)
|
|
|
|
| Weight | | 60 kg
|
|
|
|
| Scale graduation | | by request |
|
|
|
|
|
|
|
Product added to the Wishlist
| Ordering Information |
|
| Model |
|
|
|
|
|
|
|
|
|
|
| 8MRH240-60 |
|
|
|
|
|
|
|
|
|
|
|
