| Specifications |
 |
| Actuator Travel | |
|
|
|
|
| 8CMA06-13/10 | | 13mm
|
|
|
|
| 8CMA06-13/15 | | 13mm
|
|
|
|
| 8CMA06-25/15 | | 25mm
|
|
|
|
| Actuator Resolution | | 1.25µm
|
|
|
|
| Lead screw pitch | | 0.25mm
|
|
|
|
| Max.Speed | | 6mm/s
|
|
|
|
| Nominal force | | 30N
|
|
|
|
| Tip shape | | Round. Flat on request.
|
|
|
|
| Cable | | Integrated, 1.2m length
|
|
|
|
| Motorized Actuator weight | |
|
|
|
|
| 8CMA06-13/10 | | 0.12kg
|
|
|
|
| 8CMA06-13/15 | | 0.12kg
|
|
|
|
| 8CMA06-25/15 | | 0.15kg
|
|
|
|
| Motor connector | | HDB15(M)
|
|
|
|
| Stepper Motor | | 20
|
|
|
|
| Recommended controllers | | 8SMC5-USB
|
|
|
|
| Optocoupler end limit switches | | 2
|
|
|
|
| Switch polarity | | pushed is open |
|
|
|
|
|
|
|
Product added to the Wishlist
| Ordering Information |
|
| Model |
|
|
|
|
|
|
|
|
|
|
| 8CMA06-13/10* |
|
|
|
|
|
|
|
|
|
| 8CMA06-13/15 |
|
|
|
|
|
|
|
|
|
| 8CMA06-25/15 |
|
|
|
|
|
|
|
|
|
| 8CMA06V-13/15 |
|
|
|
|
|
|
|
|
|
| 8CMA06V-25/15 |
|
|
|
|
|
|
|
|
|
|
|
