Specifications |
|
Height of the vibration isolation system | | H= 500, 600, 700 mm
|
|
|
|
Vertical movement range | | 14 mm
|
|
|
|
Precision of automatic level control | | ±0.3 mm
|
|
|
|
Vertical Resonant Frequency | | 1,9 Hz
|
|
|
|
Vertical Isolation, 5 Hz | | 95 %
|
|
|
|
Vertical Isolation, 10 Hz | | 99 %
|
|
|
|
Horizontal Resonant Frequency | | 1,2 Hz
|
|
|
|
Horizontal Isolation, 5 Hz | | 99 %
|
|
|
|
Horizontal Isolation, 10 Hz | | 99 %
|
|
|
|
Max. Air Pressure | | 6 bar
|
|
|
|
Horizontal Damping | | Rubber
|
|
|
|
Max. load Capacity (set of four) | | 4000 kg
|
|
|
|
Vertical Transmissibility at Resonance | | 10 dB
|
|
|
|
Horizontal Transmissibility at Resonance | | 5 dB
|
|
|
|
Operating humidity (max) | | 90%
|
|
|
|
Operating temperature range | | 10–50 ºC
|
|
|
|
Minimal load per isolator | | 90 kg
|
|
|
|
Weight (1 isolator) | | 35kg
|
|
|
|
|
|
|
|
|
|
|
|
Product added to the Wishlist
Ordering Information |
|
Model |
|
|
|
Isolators Q-ty |
|
Height, mm |
|
Availability |
|
|
|
|
|
|
|
|
1VIS27-50-4 |
|
|
|
4 |
|
500 |
|
request |
|
|
|
|
|
|
|
1VIS27-60-4 |
|
|
|
4 |
|
600 |
|
today |
|
|
|
|
|
|
|
1VIS27-70-4 |
|
|
|
4 |
|
700 |
|
today |
|
|
|
|
|
|
|
1VIS27-custom |
|
|
|
any |
|
any height: min.- 500 max.- request |
|
request |
|
|
|
|
|
|
|
|
|
